FISCHER DuoXpand 10x100T FRAME FIXING
Fischer Frame fixing DuoXpand 10 x 100 T zinc-plated steel
- Clever combination of design and material for a secure installation in the building material.
- Expansion element with two anchoring depths for flexible use.
- Approved multiple fastening of non-load-bearing systems in concrete and masonry.
- Side ribs prevent rotation in the drill hole for convenient installation.
- Pre-assembled safety screw with countersunk head.
Attributes
- ETA-approval
- Drill diameter (d0) 10 mm
- Min. drill hole depth for through fixings (h2): 110 mm
- Usable length at anchorage depth 50mm (tfix): 50 mm
- Usable length at anchorage depth 70mm (tfix): 30 mm
- Anchor length (l): 100 mm
- Drive: TX40
Item no. 543865
$18.52
FISCHER DuoXpand 10x100T FRAME FIXING—
$18.52
Description
Fischer Frame fixing DuoXpand 10 x 100 T zinc-plated steel
- Clever combination of design and material for a secure installation in the building material.
- Expansion element with two anchoring depths for flexible use.
- Approved multiple fastening of non-load-bearing systems in concrete and masonry.
- Side ribs prevent rotation in the drill hole for convenient installation.
- Pre-assembled safety screw with countersunk head.
Attributes
- ETA-approval
- Drill diameter (d0) 10 mm
- Min. drill hole depth for through fixings (h2): 110 mm
- Usable length at anchorage depth 50mm (tfix): 50 mm
- Usable length at anchorage depth 70mm (tfix): 30 mm
- Anchor length (l): 100 mm
- Drive: TX40
Item no. 543865
